Name: MIL-DTL-26482 Connector: Shell Size 10 5-Pin Waterproof
Brand: STA Connector
SKU: 26482-10-5
Availability: InStock
Rating: 5 (1 reviews)

Description

MIL-DTL-26482 Connectors Specification

Universal Brand Compatibility: Our MIL-DTL-26482 Series I connectors are 100% intermateable with Amphenol PT series and ITT Cannon KPT, allowing for direct drop-in replacement without retooling.
Versatile Mounting Formats: From the MS3114 jam nut receptacle to the MS3116 cable plug, we provide every interface style to meet diverse panel-mount or field-wiring requirements.
Superior Environmental Armor: Featuring an aluminum alloy shell with 48-hour salt spray resistance, these connectors outperform standard industrial plugs in corrosive maritime and aerospace environments.
Fail-Safe Bayonet Locking: The 3-point bayonet system provides a vibration-resistant connection that won't decouple under 50g shocks, ensuring constant signal flow in heavy-duty robotic and defense hardware.
Precision Conductive Path: Equipped with gold-plated copper alloy contacts, our 5-pin inserts deliver low millivolt drop and stable conductivity across 500+ mating cycles in extreme temperatures.

Applications

Defense Upgrades: Replacing legacy Amphenol or ITT Cannon connectors in tactical communication kits and field radio units.
Industrial Controls: Utilizing MS3112 receptacles for secure sensor-to-PLC links in high-vibration manufacturing zones.
Aerospace Systems: Integrating MS3110 wall mounts for lightweight, compact signal routing in avionics and UAV control bays.
Marine Networking: Using MS3116 waterproof plugs for outdoor monitoring equipment exposed to salt spray and heavy humidity.
Energy Sector: Ruggedized power connections for oil and gas exploration tools requiring highly waterproof interconnects.

Shell Material:	Aluminum alloy
Shell Plating:	Olive Drab Cadmium/Black Over Zinc Plating
Contact Material:	Copper Alloy
Contact Plating:	Gold Plating
Insulator Material:	Synthetic rubber
Rated voltage:	600V
Rated current:	7.5A
Insulation Resistance:	5,000 Mega ohms minimum (at 25°C)
Contact Resistance:	≤10 mΩ

Plug or Receptacle

MS3110(PT00,SP00,PW00,KPT00,85100) – Wall Mounting Receptacle	MS3111(PT01,PW01,KPT01,85101) – Cable Connecting Plug	MS3112(PT02,PW02,KPT02,85102E-50) – Box Mounting Receptacle	MS3114(PT07,PW07,KPT07,85107) – Jam Nut Mounting Receptacle	MS3114A(PT07A,PW07A,KPT07A,85107A) – Jam Nut Receptacle	MS3116(PT06,PW06,KPT06,85106) – Straight Plug	MS3119(PTB) – Thru-Bulkhead Receptacle


A-General duty, threaded back shell	E-Environmental without Clamp	F-Grommet seal with strain relief	J-Environmental with Clamp and Cable Jacket Gland Seal (MS3116 only)	P- Environmental Potting seal


Angular Positions	Position W	Position X	Position Y	Position Z

Shell Size 8
Insert Number:	10-5	10-6	10-7	10-8
Number of Contacts:	5	6	7	6
Contact Size:	20	20	20	20

Cross-Reference & Compatibility

“A” General Duty / “C” Pressurized“

“A” (SR), “E” (SR), “P” (SR), MS / “F” Strain Relief

E” Open Wire Seal

“P” Potting Boot

“J” Cable Seal

“PG” Cable Gland Seal

PT00A-10-5S,10-5P
SP00A-10-5S,10-5P
PT00C-10-5S,10-5P
PT01A-10-5S,10-5P
PT06A-10-5S,10-5P
SP06A-10-5S,10-5P
PTG06A-10-5S,10-5P
PT07A-10-5S,10-5P
PT07C-10-5S,10-5P

PT00A-10-5S,10-5P (SR)
SP00A-10-5S,10-5P (SR)
PT00E-10-5S,10-5P (SR)
SP00E-10-5S,10-5P (SR)
PT00P-10-5S,10-5P (SR)
SP00P-10-5S,10-5P (SR)
MS3110F-10-5S,10-5P
PT01A-10-5S,10-5P (SR)
PT01E-10-5S,10-5P (SR)
PT01P-10-5S,10-5P (SR)
MS3111F-10-5S,
MS3111F-10-5P
PT01A-10-5S,PT01A10-5P (SR)
PT06A-10-5S,PT06A-10-5P (SR)
SP06A-10-5S,SP06A-10-5P (SR)
PTG06A-10-5S,PTG06A-10-5P (SR)
PT06E-10-5S,PT06E-10-5P (SR)
SP06E-10-5S,SP06E-10-5P (SR)
PTG06E-10-5S,PTG06E-10-5P (SR)
PT06P-10-5S,PT06P-10-5P (SR)
SP06P-10-5S,SP06P-10-5P (SR)
PTG06P-10-5S,PTG06P-10-5P (SR)
MS3116F-10-5S,MS3116F-10-5P
PT07A-10-5S,PT07A-10-5P (SR)
SP07A-10-5S,SP07A-10-5P (SR)
PT07E-10-5S,PT07E-10-5P (SR)
MS3114F-10-5S,10-5P

PT00E-10-5S,PT00E-10-5P
SP00E-10-5S,SP00E-10-5P
MS3110E-10-5S,MS3110E-10-5P
PT01E-10-5S,PT01E-10-5P
MS3111E-10-5S,MS3111E-10-5P
PT01E-10-5S,PT01E-10-5P
MS3111E-10-5S,MS3111E-10-5P
PT06E-10-5S,PT06E-10-5P
SP06E-10-5S,SP06E-10-5P
PTG06E-10-5S,PTG06E-10-5P
MS3116E-10-5S,
MS3116E-10-5P
PT07E-10-5S,10-5P
SP07E-10-5S,10-5P
MS3114E-10-5S,
MS3114E-10-5P

PT00P-10-5S,PT00P-10-5P
SP00P-10-5S,SP00P-10-5P
MS3110P-10-5S,
MS3110P-10-5P,
PT01P-10-5S,PT01P-10-5P
MS3111P-10-5S,MS3111P10-5P
PT01P-10-5S,PT01P-10-5P
MS3111P-10-5S,MS3111P-10-5P
PT06P-10-5S,PT06P-10-5P
SP06P-10-5S,SP06P-10-5P
PTG06P-10-5S,PTG06P-10-5P
MS3116P-10-5S,MS3116P-10-5P
PT07P-10-5S,PT07P-10-5P
MS3114P-10-5S,MS3114P-10-5P

MS3110J-10-5S
MS3110J-10-5P

MS3116J-10-5S
MS3116J-10-5P

PT01PG-10-5S
PT01PG-10-5P
PT06PG-10-5S
PT06PG-10-5P

PT02 (MS3112)SP02 box mounting receptacle

PT02A-10-5S,PT02A-10-5P
SP02A-10-5S,SP02A-10-5P
PT02C-10-5S,PT02C-10-5P
SP02C-10-5S,SP02C-10-5P

PT02E-10-5S,
PT02E-10-5P,
SP02E-10-5S,
SP02E-10-5P,
MS3112E-10-5S,
MS3112E-10-5P

PT02P-10-5S,
PT02P-10-5P,
SP02P-10-5S,
SP02P-10-5P,
MS3112P-10-5S,
MS3112P-10-5P

FAQ

Q: Can I use Staconnector MS3116 plugs with an original Amphenol PT receptacle?
A: Yes, our MIL-DTL-26482 series is designed to be fully intermateable with all major brands including Amphenol, ITT Cannon, and TE Connectivity.
Q: Which model should I choose for a panel-mount application?
A: The MS3110 (wall mount) is best for front-panel attachment, while the MS3114 (jam nut) is ideal for single-hole mounting where space is limited.
Q: Is your black zinc finish a direct alternative to military olive drab?
A: Yes, our Black over zinc plating offers the same durability but is RoHS compliant, making it the preferred choice for commercial and European markets.
Q: How do you ensure the connectors are vibration resistant?
A: Every batch undergoes EIA364.28 testing, maintaining electrical continuity even under 15g of force, matching the performance of premium military brands.
