IP67 Waterproof Protection
The threaded RJ45 13/16"Screw connector uses epoxy resin and rubber sealing to prevent water and dust ingress, ensuring stable Ethernet performance in outdoor networking, industrial automation, and harsh environment installations.
CAT5e / CAT6a High-Speed Data Transmission
Designed to meet CAT5e and CAT6a standards, this waterproof RJ45 plug supports stable high-speed Ethernet communication with low signal loss and excellent impedance control.
Durable Flame-Retardant Housing
The PA66 thermoplastic shell with UL94 V-0 flame-retardant rating offers strong mechanical protection, chemical resistance, and long-term durability in industrial network systems.
Gold-Plated Contacts for Low Resistance
Phosphor copper contacts with gold plating provide ≤5 mΩ contact impedance, ensuring reliable signal transmission and reduced data loss over repeated mating cycles.
Threaded Locking for Secure Connection
The screw-type locking structure prevents accidental disconnection caused by vibration, making this RJ45 waterproof connector ideal for machinery, control cabinets, and outdoor Ethernet links.
| OD:6.0 | OD:8.0 |
 |
 |
Industrial Ethernet connections for automation equipment and PLC control systems.
Outdoor networking systems exposed to rain, dust, and temperature variation.
Smart factory communication infrastructure using CAT5e or CAT6a Ethernet.
Transportation and mobile equipment requiring vibration-resistant RJ45 connections.
Industrial IoT gateways and waterproof network devices in harsh environments.
Q1: Is this connector compatible with standard RJ45 Ethernet cables?
Yes, it supports standard CAT5e and CAT6a Ethernet cables within the specified cable diameter range.
Q2: Can this connector be used outdoors long-term?
Yes, the IP67 waterproof rating and sealed structure make it suitable for long-term outdoor installations.
Q3: Does the threaded design improve connection reliability?
Absolutely. The threaded locking mechanism prevents loosening due to vibration or movement.
Q4: What is the expected service life?
The connector is rated for at least 750 mating cycles under normal operating conditions.
